JBL MA4505 Усилитель 5-канальный27300₽
Общие характеристики
Channels 5 - 3
POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 25 A
Idling current (power ON/OFF) 2 A / 0.04 mA
Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): 30 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART Automatic Remote Turn-On/Off with Speaker-In
AMPLIFIER STAGE
Distorsion - THD (100 Hz @ 4 Ω) 0.02 %
Bandwidth FRONT/REAR: 10 ÷ 50k Hz
Bandwidth SUB: 10 ÷ 500 Hz
S/N Ratio (A weighted @ 1 V): 100 dB
Damping factor (100 Hz @ 4 Ω) FRONT/REAR: 100
Damping factor (100 Hz @ 4 Ω) SUB: 250
Pre-In sensitivity: 0.2 ÷ 5 VRMS
Speaker-In sensitivity: 0.8 ÷ 20 VRMS
Load impedance (MIN)
@ 5 Ch: 2 Ω
@ 3 Ch: 4 Ω + 4 Ω + 2 Ω
Max size (mm / in.): 345 x 190 x 50 / 13.58 x 7.48 x 1.97
Weight (kg / lb.): 2.61 / 5.75
Adjustable Crossovers yes
Мощность
Channels 5 - 3
POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 25 A
Idling current (power ON/OFF) 2 A / 0.04 mA
Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): 30 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART Automatic Remote Turn-On/Off with Speaker-In
AMPLIFIER STAGE
Distorsion - THD (100 Hz @ 4 Ω) 0.02 %
Bandwidth FRONT/REAR: 10 ÷ 50k Hz
Bandwidth SUB: 10 ÷ 500 Hz
S/N Ratio (A weighted @ 1 V): 100 dB
Damping factor (100 Hz @ 4 Ω) FRONT/REAR: 100
Damping factor (100 Hz @ 4 Ω) SUB: 250
Pre-In sensitivity: 0.2 ÷ 5 VRMS
Speaker-In sensitivity: 0.8 ÷ 20 VRMS
Load impedance (MIN)
@ 5 Ch: 2 Ω
@ 3 Ch: 4 Ω + 4 Ω + 2 Ω
Max size (mm / in.): 345 x 190 x 50 / 13.58 x 7.48 x 1.97
Weight (kg / lb.): 2.61 / 5.75
Adjustable Crossovers yes
