Общие характеристики
Channels 4 - 3 - 2
POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 20 A
Idling current (power ON/OFF) 1.6 A / 0.04 mA
Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): 22 A
Remote In: 7 ÷ 15 VDC - 1 mA
ART Automatic Remote Turn-On/Off with Speaker-In
AMPLIFIER STAGE
Distorsion - THD (100 Hz @ 4 Ω) 0.02 %
Bandwidth: 10 ÷ 60K Hz
S/N Ratio (A weighted @ 1 V) 100 dB
Damping factor (100 Hz @ 4 Ω): 200
Pre-In sensitivity 0.2 ÷ 5 VRMS
Speaker-In sensitivity: 0.8 ÷ 20 VRMS
Load impedance (MIN)
@ 4 Ch: 2 Ω
@ 3 Ch: 2 Ω + 2 Ω + 4 Ω
@ 2 Ch: 4 Ω
Max size (mm / in.): 215 x 190 x 50 / 8.46 x 7.48 x 1.97
Weight (kg / lb.): 1.94 / 4.27
Adjustable Crossovers yes
Мощность
Output Power (RMS) @ 14.4 VDC, THD 1%:
4 Ch: 75 W x 4 (4 Ω)
4 Ch: 130 W x 4 (2 Ω)
3 Ch: 75 W x 2 (4 Ω) + 260 W x 1 (4 Ω)
3 Ch: 130 W x 2 (2 Ω) + 260 W x 1 (4 Ω)
2 Ch: 260 W x 2 (4 Ω)
Output Power (RMS) @ 14.4 VDC, THD 10%:
4 Ch: 85 W x 4 (4 Ω)
4 Ch: 145 W x 4 (2 Ω)
3 Ch: 85 W x 2 (4 Ω) + 290 W x 1 (4 Ω)
3 Ch: 145 W x 2 (2 Ω) + 290 W x 1 (4 Ω)
2 Ch: 290 W x 2 (4 Ω)
CEA 2006-A Ratings:
RMS Power (4 Ω, ≤1 %THD + N, 14.4 V): 70 W x 4 Ch
S/N Ratio (ref. 1 W output): 80 dBA
Total Power 1160 W
